Kode error AC VRV 2 Daikin

  Mitra Teknik AC



Kode error AC VRV 2 Daikin



AC VRV 2 Merek Daikin

No Unit Kode Masalah

1
Indoor
A0
Eror external pro tection device
2
A1
Pc board defect,e2PROM defect
3
A3
Malfunction of drain level control system(S1L)
4
A6
Fan motor(M1F) lock,overload
5
A7
Malfuntion of swing flap motor(MA)
6
A9
Malfuntion of moving part of elektronic expansion valbe (20E)
7
AF
 Drain level about limit
8
AH
 Manfuntionof air filter maintennce
9
AJ
Malfuntion of capacity setting
10
C4
Malduntion of thermistor(R2T)for heat exvhange(loose conection,disconection,shot sircuit,failur)




11
C5
Malfuntiom of thermistor(R3T)for gas pipe
12
C9
Malfuntion of thermistor(R1T)for air inlet
13
CJ
Malfuntion of thermostat sensor in remot control
14
E1
PC Board defect
15
E3
Actuation high presure switch
16
E4
Acruation of low presure sensor
17
E5
Compresor motor lock
18
E6
Standard compresor lock over carrent
19
E7
Malfuntion of outdoor unit fan motor
20
 E9
Malfuntion of moving part of electronic expantion valve (Y1E-3E)
21   F3 Abnormal discharge pipe temperatur
21   F6 Refrigrant over charged
23   H3 Malfuntion of high presure switch
24   H4 Malfuntion of low preasure switch
25   H7 Abnormal outdoor fan motor signal
26   H9 Malfuntion of thermistor(R1T)for outdoor air
27   J2 Carrent sensor malfuntion
28   J3 Malfuntion of discharge pipe thermistor(R31-33T)
29   J5 Malfuntion of thermistor(R2T) foe suction pipe
30   J6 Malduntion of thermistor(R4T) for heat exharger
31   J7 Malfuntion of receiver outlet liquid pipe thermistor (R6T)
32   J9 Malfuntion of subcoolling heat exhanger gas pipe thermistor(R5T)
33   Ja Malfuntion of discharge pipe pressure sensor
34   JC Malfuntion of suction pipe pressure sensor
35   L0 Inverter system eror
36   L4 Malfuntion of inverter radiating fin temperatur rise
37   L5 Inverter compresor motor grounding,short circuit
38   L6 Compresor motor coil grounding on short circuit
39   L8 Inverter carrent abnormal
40   L9 Inverter start up error
41   LA Malfuntion of power unit
42   LC Malfuntion of transmision betwen inverter and control pcb
43   P1 Inverter over-ripple protection
44    P4 Malfuntion of inverter radiating fin temperatur rise sensor
45   U0 Low pressure drop due yo refrigrant shortage or elektronic expansion valve failure
46   U1 Reverse phase/open phase
47   U2 Power supply insufficient or instantaneous failure
48   U3 Check operation is not conducted
49   U4 Malfuntion of transmition betwen indoor and outdoor unit
50   U5 Malfuntion of transmission betwen remot control and indoor unit
51   U5 Failure of remote control pcb or setting durring control by remote controler
52   U7 Malfuntion off transmition betwen outdoor units
53   U8 Malfuntion of transmition betwen main and sub remote control
54   U9 Malfunction of transmition betwen indoor and outdoor units in the same system
55   UA Improper combination of indoor and outdoor units,indoor unit and remote control
56
UC Adress duplication of centralized controler
57   UE Malfuntion of transmition betwen centralized controler and indoor unit
58   UF System is not set yet
60   UH Malfuntion of system,refrigrant system addres undefined
61   M1 PC Board defect
62   M8 Malfuntion of transmition between optional controler for centralized cintrol
63   MA Improper combination of optional controlers for centralized control
64   MC Addres duplication,improper setting
65   UE Malfuntion of transmition between cemtralized controler and indoor unit
66   M1 PCBoard defect
67   M8 Malfunction of transmission between optional controlers for centralized control
68   MA Improper combination of optional controllers for centralized contol
69   MC Addres duplication,improper setting
